| XR | |
|---|---|
| Vehicle model | KK1121D10 |
| Vehicle status | 73.6V 10.5KW |
| Right hand drive | ○ |
| Basic parameter | |
| Length x width x height (mm) | 3650×1510×1820 |
| Container interior dimensions | 1620X1245X300 |
| Wheelbase (mm) | 2340 |
| Front wheel base（mm） | 1315 |
| Rear wheel base（mm） | 1315 |
| Front suspension（mm） | 455 |
| Rear suspension（mm） | 705 |
| Maintenance weight（kg） | 850 |
| Load weight （kg） | 300 |
| Number of passengers | 2 |
| Total mass（kg） | 1280 |
| performance parameter | |
| Maximum speed（km/h） | 80 |
| Acceleration time s | 20（0-60km） |
| Maximum climbing grade | 35% |
| Minimum turning diameter（m） | ≤11 |
| Maximum Angle | 30(External wheels) /32(Internal wheels) |
| Approach Angle（°） | ≥55 |
| Departure Angle（°） | ≥35 |
| Minimum ground clearance（mm, no load） | ≥200 |
| Battery/motor parameters | |
| Power battery Specification（V/Ah） | 73.6V，240 Ah Lithium |
| Battery type | lithium iron phosphate battery |
| Lithium battery heating plate | ● |
| Driving range （no-load）（km） | ≥200 (straight line driving at a constant speed of 40km/h) |
| 220V car charger | - |
| 110~220V vehicle mounted （wide voltage） | ● |
| Charging time （20%-100%）（h） | 6~8 |
| Motor type | Ac induction motor |
| Rated power（kw） | 10.5KW |
